LTM4616V

Dual, 8A, 2-phase, switch mode, power regulator system, 15mm ×15mm, surface mount, LGA package

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~2.00

PartNumber:: LTM4616V

Brand:: Linear Technology - Linear | Pack: LGA | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. vivian's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-30

From Other Seller

Part Number:LTM4616V
US $0.50 - 2.00
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LTM4616V is a complete dual 2-phase 8A per channel switch mode DC/DC power regulator system in a 15mm ×15mm surface mount LGA package. Included in the package are the switching controller, power FETs, inductor and all support components. Operating from an input voltage range of 2.7V to 5.5V, the LTM4616V supports two outputs within a voltage range of 0.6V to 5V, each set by a single external resistor. This high efficiency design delivers up to 8A continuous current (10A peak) for each output. Only bulk input and output capacitors are needed, depending on ripple requirement. The part can also be configured for a 2-phase single output at up to 16A.

Parametrics

LTM4616V absolute maximum ratings: (1)VIN1, SVIN1, VIN2, SVIN2: -0.3V to 6V; (2)CLKOUT1, CLKOUT2: -0.3V to 2V; (3)PGOOD1, PLLLPF1, CLKIN1, PHMODE1, MODE1, PGOOD2, PLLLPF2, CLKIN2, PHMODE2, MODE2: -0.3V to VIN; (4)ITH1, ITHM1, RUN1, FB1, TRACK1, MGN1, BSEL1, ITH2, ITHM2, RUN2, FB2, TRACK2, MGN2, BSEL2: -0.3V to VIN; (5)VOUT1, VOUT2, SW1, SW2: -0.3V to VIN; (6)Internal Operating Temperature Range: -40℃ to 125℃; (7)Junction Temperature: 125℃; (8)Storage Temperature Range: -55℃ to 125℃.

Features

LTM4616V features: (1)Complete Dual DC/DC Regulator System; (2)Input Voltage Range: 2.7V to 5.5V; (3)Dual 8A Outputs, or Single 16A Output with a 0.6V; (4)to 5V Range; (5)Output Voltage Tracking and Margining; (6)亇1.75% Total DC Output Error (.40℃ to 125℃); (7)Current Mode Control/Fast Transient Response; (8)Power-Good Tracking and Margining; (9)Overcurrent/Thermal Shutdown Protection; (10)Onboard Frequency Synchronization; (11)Spread Spectrum Frequency Modulation; (12)Multiphase Operation; (13)Selectable Burst ModeR Operation; (14)Output Overvoltage Protection; (15)Gold-Pad Finish Allows Soldering with Pb and Pb; (16)Free Solder Paste; (17)Small Surface Mount Footprint, Low Profi le; (18)LGA Package.
