Product Summary

The MAX8695GELR is a P-channel load switch. It features an accurate user-set current limit and low on-resistance. This switch is designed to protect your power source from shorts and surges by limiting current and preventing the system supply from being pulled low. The input voltage range is 2.7V to 5.5V. The MAX8695GELR is suitable for Universal Serial Bus (USB), Notebook Computers, Personal Communicators, Palmtop Computers, Hand-Held Instruments and Portable Medical Instruments.

Parametrics

MAX8695GELR absolute maximum ratings: (1)IN to GND: -0.3V to 6V; (2)ON, FAULT to GND: -0.3V to 6V; (3)SET, OUT to GND: -0.3V to (VIN + 0.3V); (4)Maximum Continuous Switch Current: 3A; (5)Continuous Power Dissipation: 667mW; (6)Operating Temperature Range: -40 to +85℃; (7)Storage Temperature Range: -65 to +150℃; (8)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX8695GELR features: (1)Very Small Footprint (16-pin QSOP is the same size as an 8-pin SO); (2)Low Resistance: 45m? at 3V; (3)±21%-Accurate, User-Set Current Limit; (4)12μA (typ) Quiescent Current; (5)0.01μA (typ) Shutdown Current; (6)0.04μA (typ) Leakage to Output when Switch is Off; (7)2.7V to 5.5V Input Range; (8)Thermal Shutdown; (9)Fault Output.

Diagrams

MAX8695GELR functional diagram
