Product Summary
The NL10276AC30-07 is a kind of TFT color LCD module. The NL10276AC30-07 is composed of the driver LSIs for driving the TFT (Thin Film Transistor) array with an amorphous silicon thin film transistor liquid crystal display (a-Si TFT LCD) panel structure and a backlight. The a-Si TFT LCD panel structure of the NL10276AC30-07 is injected liquid crystal material into the narrow gap between a TFT array glass substrate and a color filter glass substrate. The NL10276AC30-07 is widely used in FA monitor.
Parametrics
NL10276AC30-07 absolute maximum ratings: (1)Supply voltage: LCD panel signal board, VDD: -0.3 to +6.0 V; Inverter, VDDB: -0.3 to +15.0 V at Ta = 25℃; (2)Input voltage: Display signals, Vi: -0.3 to +3.8 V at Ta = 25℃, VDD=5.0V; BRTC, ViB1: -0.3 to +5.5 V; BRTP, ViB2: -0.3 to +5.5 V; PWSEL, ViB3: -0.3 to +5.5 V; ACA, ViB4: -0.3 to +5.5 V; BRTL, ViB5: -0.3 to +1.5 V at Ta = 25℃, VDDB=12V; (3)Storage temperature, Tst: -20 to +60℃; (4)Operating temperature: Top1: 0 to +55 at Module front surface; Top2: TBD ℃ at Module rear surface.
Features
NL10276AC30-07 features: (1)parallel 8bit interface (2 port); (2)ultra-wide viewing angle (with lateral electric field); (3)fast response time; (4)high luminance; (5)high contrast; (6)wide color gamut; (7)luminance control; (8)small foot print; (9)direct light type; (10)replaceable backlight unit and inverter.
